Schneider Electric Illuminated pushbutton

24VAC/DCType: LED NO+NCProduct description: Pushbuttons, rotary and key switches Harmony Style 5 (Series XB5) plastic Ø 22 mm - Complete units - Mushroom pushbutton, black Ø40mmPushbutton program Harmony style 5The pushbutton program Harmony style 5 refers to the series of pushbuttons, signal lamps and lamp switches with plastic front rings. The series model numbers start with XB5 and replace the Ø22 mm XA2-B series. However, the XA2-B series is still used with the XAC pendant switch program and is therefore included in this catalog. See section on pendant switches.Signal lamps and lamp switches now use Protected LED technology, which provides up to 100,000 hours of maintenance-free operation. The advantages of the new LEDs compared to traditional incandescent bulbs include:less maintenanceno need for bulb testingall colors available (including blue and white)wide voltage range with same light intensity: 12V and 230V (See limit values ​​on page 311).Connection can be made either via screws with locking washers, plugs or pins for printed circuit boards.The program consists of:Complete units XB5-AComponents for assembly ZB5-ALoose parts and accessories ZB5-AThe complete units consist of:Mushroom pushbuttons flush-mounted, flush-mounted with silicone cap raised buttons , double-push buttons , emergency stop (push-pull , press-turn , emergency stop key according to EN418), rotary switch es,key switch es.Signal lamps (3 types):With built-in LED sfor BA9s incandescent bulbswith direct supplyand transformer.Lamp switches(5 types):Roundwith built-in LEDsfor BA9s incandescent bulbswith direct supplyand transformer.Double lamp switchwith built-in LEDand rotary knobswith built-in LED.Signs(common to XB4 ​​and XB5 ​​series)The signs can be designed by the user using design software provided on a diskette.Ø 22 mm timers, sounders and fuse holdersAmong other products from the Harmony style 5 series are:timers from 0 to 9999.9 hourssounders, 80DBfuse holders for 5x20mm fusesTechnical specifications:Color: GreenVoltage (V):
